What vehicles have a Ford 8.8 rear end?
- 1986-2014 Ford Mustang.
- 1982-2012 Ford F-150.
- 1982-1996 Ford Bronco.
- 2001-2005 Ford Explorer Sport Trac.
- 1991-2011 Ford Ranger 4.0L models.
- 1991-2001 Ford Explorer (Solid axle)
- 1985-2011 Ford Panther platform vehicles.
.
Then, how do I identify a Ford 8.8 rear end?
You can identify the Ford 8.8-inch rear by its rear cover. It has a thin metal or plastic 10-bolt cover, and the bolts are 7/16-inch thread. The cover is not quite square, measuring about 101/2 inches high by 11 inches long. The 8.8-inch pinion shaft is 15/8 inches and has 30 splines.
how can you tell the difference between a Ford 7.5 and 8.8 rear end? How to Tell the Difference Between an 8.8 and a 7.5 Rear End
- Locate the axle tag. It is attached to the rear differential cover by one of the bolts, usually the top middle one.
- Note the three sets of numbers across the bottom of the tag. The middle number will be "7.5" or "8.8." This is the size of the rear axle.
- Place a drain pan under the differential.
Beside this, what is a 8.8 Ford rear end?
The 8.8 is a C-clip rearend, which is a major weak point because if you break an axle, it can come out of the housing, and you'll lose the wheel and probably quarter-panels while you're at it. The aftermarket sells C-clip-eliminator kits that retain the axles with flanges at the ends of the axletubes.
Are all Ford 8.8 carriers the same?
The gears are all the same for Ford 8.8s. The carriers usually come in two different sizes, depending on gear ratio. A full locker will replace the spider gears so it'll need to be the same spline count.
Related Question AnswersHow strong is a Ford 7.5 rear end?
Yes the 7.5 can handle 400 rwhp but that's getting close to the fringe. General rule of thumb is about 350 rwhp. The new rear end is definitely not the first thing to be done.What did a Ford 8.8 come in?
8.8 Solid Axle Ford first used the 8.8 axle in 1983 model year trucks and is still in production for the Ford Ranger and Ford F-Series. It was also used in the Ford SUVs until Independent suspension replaced the solid axle. Ring, pinion and carrier all remained between the solid axle and independent rear suspension.How do you identify a differential?
Without an ID tag, differentials are identified by the number of cover bolts, the distinctive shape of the cover, the number of ring gear bolts, and ring gear diameter. They can also be identified by whether the center section is an integral or dropout design.How wide is a Ford Explorer 8.8 rear end?
| Axle Dimensions | ||
|---|---|---|
| Ranger 1983-1992 7.5-Inch Axle | Explorer 8.8 | |
| Width WMS-WMS | 56-1/2 inches | 59-1/2 inches |
| Axle tube diameter (1983-2009 models): | 2.80 inches | 3.25 inches |
| Pinion Offset Right Of Center | unk | 2 inches |
How much power can a Ford 7.5 handle?
"All v6 mustangs come with 7.5 rear ends with an open carrier differential. They can roughly handle 300hp. Using sticky tires, such as slicks, and launching at high rpms can cause breaking even if you do not have 300hp."Why is Ford 9 inch rear end so popular?
Because the pinion rides so low on the ring gear, there is more tooth contact between the ring and pinion. The nose bearing on the pinion also helps make it a really strong gear assembly. No other axle has more gear ratios available for it than the Ford 9-inch.How much power will a Ford 8.8 handle?
Now strange has desighned a new spool for the 8.8 to handle more power and 35 spline axels, so with the right parts and prep an 8.8 will hold 800-1000 hp no problem!How strong is a 8.8 rear end?
8.8 is fine up to 1,200hp or so. just weld the tubes, build a brace off the center section to the tubes, and weld 9in ends on it for the desired width. Well the one that is in the car has 31 spline strange axles, an auburn pro series differential, 4.10 gears and the factory drum brakes.What Fords came with 9 rear end?
Common applications- 1957-1986 Ford F-100 & F-150.
- 1976-1982 Ford Granada.
- 1976-1979 Lincoln Versallies.
- 1957-1970 Ford Fairlane.
- 1957-1971 Ford Thunderbird.
- 1964 1/2-1973 Ford Mustang.
- 1966-1983 Ford Bronco.
- 1967-1984 Ford Falcon (Australia)
